Typhoon™ Extruder

Higher Flow Rate. Faster Printing.

Typhoon™ is described as high flow and fast print all-in-one extruder toolhead specifically designed for industrial large-scale 3d printers. This print head is designed to extrude 2.85mm filament, is compatible with standard firmware and is capable of outputting a flow around 200mm³/s (0.9 kg/h). This means quicker print at a high deposit rate.

Parameter	Value	Units
Weight	~1750	g
Filament size	2.85	mm
Maximum output flow	200	mm3/s
Max printing temperature	500	°C
Max environment temperature	100	°C
Available heatcore sizes	0.60 0.90 1.20 1.80 2.50	mm
Total height	224	mm
Heating power	400	W
